Reliable Wheel Mucking Loader Sell

Air-friendly Operation: Minimizes tunnel air pollution, creating a healthier construction environment.

Smooth Conveyance: Enables continuous material transport, shortening transfer time and accelerating project progress.

Space Adaptability: Fits various tunnel sections, operational in both narrow and spacious environments.

Flexible Dual Drive: Electric-diesel dual drive switches freely between in-mine and out-of-mine scenarios.

Contact Now

Product Details

This equipment utilizes an electric full - hydraulic transmission system and combines four vital functions: hydraulic locomotion, excavation and collection, material conveyance, and loading. Featuring a streamlined and compact design, it provides substantial thrust and has a wide mucking coverage area. Its primary operations are governed by pilot - controlled valves, ensuring an intuitive and seamless operation. This not only ensures safety and comfort but also offers excellent maneuverability, robust climbing capabilities, and a smooth, vibration - free performance.

Capable of loading rocks across the entire cross - section without any blind spots, it eliminates the requirement for manual cleaning of the working face. This significantly boosts productivity, cuts mining costs, and maximizes economic returns. With the capacity to discharge 50 - 60 cubic meters of materials per hour, a single unit can effectively replace the workload of over 30 workers. This reduction in the number of operators not only streamlines the workforce but also mitigates potential safety risks during operation.

Wheel Mucking Loader

DETAIL PRESENTATION

Wheel Mucking Loader

PRODUCT SELLING POINTS

	01 Excavator Bucket By adoption of the similar excavation bucket and teeth, making the digging much easier and regaining efficiency.
02 Conveying System Taking advantage of specially designed wear-resistant and durable conveying belt, withstanding all type of rock and gravels.
	03 Core Engine Stable Diesel Engine or Electric Motor from Reliable Factory with high performance, powerful and speedy.
04 Hydraulic Ram As a key component of operation effect, we use high quality hydraulic cylinders for the boom, dipper arm and other units.
	05 Simple Operation Straight-forward arrangement of levers to ensure a smooth operation in any working scenario.
06 Chassis and Tyre The multi-layer spring plates reinforced chassis is and robust tyres bring stability to the entire machine

Wheel Mucking Loader

PRODUCT SPECIFICATION

Model	BJ1.5-70T-B
Loading Capacity (m³/h)	≤ 70
Total Machine Mass (kg)	Approximately 3800±5%
Wheelbase (A) (mm)	1550
Track Width (Front/Rear) (mm)	1250/1220
Minimum Turning Radius (m)	≤ 5
Excavation Width (B) (mm)	3000
Digging Reach (C) (mm)	1600
Loading Width (Z) (mm)	650
Excavation Height (H) (mm)	2050
Maximum Dumping Height (H) (mm)	1500 (Can be Raised)
Loading Length (D) (mm)	1600 (Can be Extended)
Gradability (°)	≤ 5
Maximum Dimension of Pass - through Material (mm)	≤ 640×500
Conveyor Belt Speed (m/s)	0.8±5%
Conveying Capacity (m³/h)	≥ 60
Main Motor Power (Kw)	11
Traveling Speed (Km/h)	1.45
Rated Working Pressure (Mpa)	12
Relief Valve Opening Pressure (Mpa)	12.5
Electrical Insulation Strength (MΩ) - Three - phase	≥ 1.5
Electrical Insulation Strength (MΩ) - Phase - to - phase	≥ 1.5
Maximum Dimensions in Transport State (mm) - Length	6300±50
Maximum Dimensions in Transport State (mm) - Width	1500±50
Maximum Dimensions in Transport State (mm) - Height	1500±50
Minimum Applicable Cross - section (㎡)	2.2×2.2

PRODUCT DISPLAY

Wheel Mucking Loader

PRODUCT APPLICATIONS

Wheel Mucking Loader

ABOUT US

Shandong Beijun Machinery Industry Co., Ltd. distinguishes itself as a preeminent enterprise with an unswerving dedication to the research, innovation, and production of mining and construction machinery. Located in Jining, Shandong, the company spans a large area of 100 acres, boasting a 20,000 - square - meter production facility. By utilizing advanced - level manufacturing technologies, Beijun is able to achieve an annual production capacity of 4,000 mining trucks, 500 fully - hydraulic crawler vehicles, and 3,000 aerial work platform trucks.

Beijun has duly obtained the ISO9001 quality management system certification and the EU CE accreditation. It scrupulously complies with mining safety and production norms. The firm implements a comprehensive ERP system, integrating sophisticated information technology methods to enhance resource planning and elevate management efficiency. Beijun mainly focuses on manufacturing mining transport vehicles, crawler haulage machinery, and aerial work platform trucks.

Supported by a proficient technical personnel team, stringent quality control procedures, contemporary testing equipment, and effective production methodologies, the company consistently provides high - quality products. Beijun employs over 200 staff, including 30 engineers, 40 salespersons, and 15 mechanical engineering experts.

Committed to innovation and independent R & D, Beijun firmly adheres to its core tenets of "Quality - First, Customer - Oriented." Its product range has received widespread praise in the African, South American, and Southeast Asian markets, strengthening Beijun's standing as a trustworthy and innovative industry pacesetter.
