Wheeled Mucking Rock Loader Sale

Outstanding Energy Conservation: Streamlines energy usage, minimizing wastage to achieve long - term cost - effectiveness.

Intuitive Operation: With straightforward controls, it simplifies the operation process, making it accessible and easy to use.

Swift Maintenance: Thanks to its rational structure, it allows for rapid fault identification, saving both time and effort during upkeep.

Comprehensive Efficiency: Combines excavation, loading, and conveying functions, ensuring a smooth and continuous workflow.

Contact Now

Product Details

The BJ - 70T - C wheeled mucking rock loader serves as a highly efficient piece of equipment, engineered for uninterrupted ore extraction. Mainly, it is used for digging out rock - lined and semi - coal rock roadways in mines. Moreover, it can be applied to loading operations in diversion tunnels, during the building of railway tunnels, and in the construction of national defense caverns.

This loader pairs perfectly with our company’s hydraulic mine drilling trucks. When combined, they streamline the mine excavation process, bringing it to an automated level and greatly increasing the excavation rate. It is especially well - adapted for operations in confined, small - cross - section areas and on inclined surfaces.

Wheel Mucking Loader

DETAIL PRESENTATION

Wheel Mucking Loader

PRODUCT SELLING POINTS

	01 Excavator Bucket By adoption of the similar excavation bucket and teeth, making the digging much easier and regaining efficiency.
02 Conveying System Taking advantage of specially designed wear-resistant and durable conveying belt, withstanding all type of rock and gravels.
	03 Core Engine Stable Diesel Engine or Electric Motor from Reliable Factory with high performance, powerful and speedy.
04 Hydraulic Ram As a key component of operation effect, we use high quality hydraulic cylinders for the boom, dipper arm and other units.
	05 Simple Operation Straight-forward arrangement of levers to ensure a smooth operation in any working scenario.
06 Chassis and Tyre The multi-layer spring plates reinforced chassis is and robust tyres bring stability to the entire machine

Wheel Mucking Loader

PRODUCT SPECIFICATION

Model	-	BJ-70T-C
Overall Dimensions (Length×Width×Height)	mm	5500×1500×1500
Loading Capacity	m³/h	≤70
Total Machine Mass	kg	3100
Excavation Width	mm	3000
Excavation Height	mm	2000
Excavation Depth	mm	≤550
Applicable Climbing Gradient	(°)	≤5 (Hard Ground)
Minimum Cross - section of Applicable Roadway	m	2.2×2.2
Digging Reach	mm	1600
Minimum Turning Radius	(°)	≤5
Dumping Height	mm	1500 (Can be Increased)
Dumping Distance	mm	1600 (Can be Extended)
Motor Power	kw	15
Traveling Speed	m/s	1.45±5%
Maximum Dimension of Pass - through Material	mm	600×500
Track Width	mm	1250/1220
Wheelbase	mm	1550

PRODUCT DISPLAY

Wheel Mucking Loader

PRODUCT APPLICATIONS

Wheel Mucking Loader

ABOUT US

Shandong Beijun Machinery Industry Co., Ltd. distinguishes itself as a cutting - edge enterprise that focuses on the research, development, and fabrication of mining and construction machinery. Nestled in Jining, Shandong, the company covers an area of 100 acres and runs a production plant spanning 20,000 square meters. By applying the latest manufacturing technologies, Beijun is able to produce 4,000 mining trucks, 500 fully hydraulic crawler vehicles, and 3,000 aerial work platform trucks annually.

Beijun has been accredited with the ISO9001 quality management system certification and meets EU CE standards, strictly following mining safety requirements. The company implements an all - encompassing ERP system, incorporating advanced information technology approaches to enhance resource planning and boost operational effectiveness. Its main business lies in manufacturing mining transport vehicles, crawler hauling machinery, and aerial work platforms.

With the support of a proficient technical workforce, strict quality control procedures, modern testing apparatus, and efficient production methods, the company constantly supplies high - quality products. Employing more than 200 individuals, among whom 30 are engineers, 40 are sales professionals, and 15 are mechanical engineering specialists, Beijun combines professional knowledge with innovative thinking.

Dedicated to innovation and independent research and development, Beijun firmly sticks to its core values of "Quality Paramount, Customer - Oriented." Its product range has gained extensive acclaim in the African, South American, and Southeast Asian markets, reinforcing the company’s status as a reliable and innovative industry pacesetter.
