Powerful Wheel Mucking Loader Sell

Exceptional Loading Capability: Varying by model and specification, it can handle different volumes of debris with ease.

Agile Operation: Boasting outstanding maneuverability, it can function efficiently even in tight and restricted spaces.

Sturdy and Long - lasting Construction: Given the harsh working conditions it endures, it utilizes wear - resistant materials and advanced techniques to increase its lifespan.

Superior Safety Features: Fitted with a range of safety precautions, it safeguards the well - being of operators at all times.

Contact Now

Product Details

The High - Performing Wheel Mucking Loader is designed specifically for tunnel construction and debris removal, providing powerful functions in confined spaces. Equipped with a cutting - edge track system, this machinery ensures excellent mobility and stability, even in challenging underground environments. It integrates multiple operations including excavation, loading, and transportation, ensuring high - level efficiency and reducing operating costs. This loader comes with an advanced electro - hydraulic control system that offers two power options: electric and diesel. For underground operations, electric power is recommended as it helps to reduce emissions and enhance safety. With its compact design and sturdy build, the loader is an ideal choice for tunneling projects, delivering reliable performance and maximum productivity.

DETAIL PRESENTATION

Wheel Mucking Loader

PRODUCT SELLING POINTS

01 Chassis and Tyre The multi-layer spring plates reinforced chassis is and robust tyres bring stability to the entire machine
	02 Simple Operation Straight-forward arrangement of levers to ensure a smooth operation in any working scenario.
03 Hydraulic Ram As a key component of operation effect, we use high quality hydraulic cylinders for the boom, dipper arm and other units.
	04 Core Engine Stable Diesel Engine or Electric Motor from Reliable Factory with high performance, powerful and speedy.
05 Conveying System Taking advantage of specially designed wear-resistant and durable conveying belt, withstanding all type of rock and gravels.
	06 Excavator Bucket By adoption of the similar excavation bucket and teeth, making the digging much easier and regaining efficiency.

Wheel Mucking Loader

PRODUCT SPECIFICATION

Model	-	BJ-70T1-C
Overall Dimensions (Length × Width × Height)	mm	5500 × 1500 × 1500
Loading Capacity	m³/h	≤ 70
Total Machine Mass	kg	3100
Excavation Width	mm	3000
Excavation Height	mm	2000
Excavation Depth	mm	≤ 550
Applicable Climbing Gradient	°	≤ 5 (Hard Ground)
Minimum Cross - section of Applicable Roadway	m	2.2 × 2.2
Digging Reach	mm	1600
Minimum Turning Radius	°	≤ 5
Dumping Height	mm	1500 (Can be Increased)
Dumping Distance	mm	1600 (Can be Extended)
Motor Power	kW	15
Traveling Speed	m/s	1.45 ± 5%
Maximum Dimension of Pass - through Material	mm	600 × 500
Track Width	mm	1250/1220
Wheelbase	mm	1550

PRODUCT DISPLAY

Wheel Mucking Loader

PRODUCT APPLICATIONS

Wheel Mucking Loader

ABOUT US

Shandong Beijun Machinery Industry Co., Ltd. distinguishes itself as a premier enterprise engaged in the research, development, and fabrication of mining and construction machinery. Situated in Jining, Shandong, the company occupies a vast area of 100 acres and houses a 20,000 - square - meter manufacturing plant. Through the utilization of advanced production technologies, Beijun achieves an annual production capacity of 4,000 mining trucks, 500 fully hydraulic crawler vehicles, and 3,000 aerial work platform trucks.

Beijun has successfully obtained the ISO9001 quality management system accreditation and the EU CE approval. It strictly complies with mining safety production norms. The company has implemented a comprehensive ERP system, incorporating sophisticated information technology solutions to boost resource planning and management effectiveness. Beijun mainly focuses on the production of mining transport vehicles, crawler hauling equipment, and aerial work platform trucks.

Supported by a highly skilled technical team, strict quality control processes, contemporary testing facilities, and effective production strategies, the company continuously provides top - quality products. Beijun has more than 200 employees, including 30 engineers, 40 sales representatives, and 15 mechanical engineering experts.

Dedicated to innovation and independent research and development, Beijun firmly adheres to its core tenets of "Quality Uppermost, Customer - Centric." Its product portfolio has received widespread praise in the markets of Africa, South America, and Southeast Asia, further strengthening Beijun's standing as a reliable and innovative industry pacesetter.
